RBMK reactors
Type of Soviet nuclear power reactor
What was RBMK reactors?
The RBMK (Russian: Реактор большой мощности канальный, РБМК; reaktor bolshoy moshchnosti kanalnyy, "high-power channel-type reactor") is a class of graphite-moderated nuclear power reactor designed and built by the Soviet Union. It is somewhat like a boiling water reactor as water boils in the pressure tubes. It is one of two power reactor types to enter serial production in the Soviet Union during the 1970s, the other being the VVER reactor. 4 cm (inner) diameter pipe (called a "technological channel"). The channels also contain the coolant, and are surrounded by graphite. The RBMK is an early Generation II reactor and the oldest commercial reactor design still in wide operation.
Background and consequences
Certain aspects of the original RBMK reactor design had several shortcomings, such as the large positive void coefficient, the 'positive scram effect' of the control rods and instability at low power levels—which contributed to the 1986 Chernobyl disaster, in which an RBMK experienced an uncontrolled nuclear chain reaction, leading to a steam and hydrogen explosion, large fire, and subsequent core meltdown. Radioactive material was released over a large portion of northern and southern Europe—including Sweden, where evidence of the nuclear disaster was first registered outside of the Soviet Union, and before the Chernobyl accident was communicated by the Soviet Union to the rest of the world.
Why it matters
The disaster prompted worldwide calls for the reactors to be completely decommissioned; however, there is still considerable reliance on RBMK facilities for power in Russia with the aggregate power of operational units at almost 7 GW of installed capacity. Most of the flaws in the design of RBMK-1000 reactors were corrected after the Chernobyl accident and a dozen reactors have since been operating without any serious incidents for over thirty years. RBMK reactors may be classified as belonging to one of three distinct generations, according to when the particular reactor was built and brought online: Generation 1 – during the early-to-mid 1970s, before OPB-82 General Safety Provisions were introduced in the Soviet Union.
